48Gbps 4x1 HDMI/USB-C Auto Switcher with 8K60 and EDID Management
KanexPro SW-4X1HDUSBC 4x1 auto switcher: 3 HDMI 2.1 + 1 USB-C (DP Alt Mode) in, 1 HDMI out. 48Gbps, 8K@60Hz 4:2:0, 4K@120Hz, VRR, ALLM, HDCP 2.3, EDID…
Plug in a laptop over USB-C or a media player over HDMI and the display follows, with no adapter in the signal path. The KanexPro SW-4X1HDUSBC is a 4×1 auto switcher with three HDMI 2.1 inputs and one native USB-C input (DisplayPort 1.4 Alt Mode) feeding a single HDMI output, in an ultrathin metal enclosure (145 × 68 × 18 mm). The HDMI inputs carry up to 48Gbps FRL for 8K@60Hz 4:2:0 12-bit or 4K@120Hz 4:4:4 12-bit; the USB-C input carries up to 32Gbps for 8K@30Hz 4:2:2 10-bit or 4K@120Hz 4:2:2 10-bit. Compliant with HDMI 2.1, HDCP 2.3 and DP 1.4, the switcher passes VRR, ALLM, QMS, QFT and SBTM for gaming and professional displays. HDR10, HDR10+, Dolby Vision and HLG keep their metadata end to end, and audio including LPCM 7.1, Dolby TrueHD, Dolby Atmos, DTS-HD Master Audio and DTS:X passes through uncompressed. Auto switching selects a newly connected or powered-on source; the front-panel button or IR remote switches by hand, and CEC passes from the TV to the source. A 3-pin EDID DIP switch sets one of 8 presets, from copying the display's EDID (default) to fixed FRL 12G or 10G 8K HDR modes with 2ch, 5.1ch or 7.1ch audio, so identical rooms can be set to the same handshake. Something that surprises people: not every USB-C port or cable carries video, so the source and cable must support DP Alt Mode. Powered by the included 5V/1A supply (CE, FCC and UL certified).
- Routes 3× HDMI 2.1 and 1× native USB-C input to 1× HDMI output — eliminates adapter dependency in mixed-source environments
- HDMI video bandwidth up to 48Gbps FRL and 18Gbps TMDS; USB-C video bandwidth up to 32Gbps via DisplayPort 1.4 Alt Mode
- Supports resolutions up to 8K@60Hz 4:2:0 12-bit and 4K@120Hz 4:4:4 12-bit (HDMI), and 8K@30Hz 4:2:2 10-bit and 4K@120Hz 4:2:2 10-bit (USB-C)
- Full HDMI 2.1 protocol support including VRR, ALLM, QMS, QFT, and SBTM for gaming and professional displays
- HDR, HDR10, HDR10+, Dolby Vision, and HLG pass-through preserves HDR metadata end-to-end
- LPCM 7.1CH, Dolby TrueHD, Dolby Atmos, DTS-HD Master Audio, and DTS:X audio pass-through
- Auto input switching detects newly connected or powered-on sources; manual switching via front-panel button or IR remote
- Advanced EDID management via 3-pin DIP switch with 8 presets including sink copy, FRL 12G/10G, and configurable audio formats
- CEC pass-through enables TV-to-source control; ultrathin metal housing (145 × 68 × 18 mm); included 5V/1A power supply is CE, FCC, and UL certified
Specifications| HDMI Compliance | HDMI 2.1 |
|---|
| HDCP Compliance | HDCP 2.3 |
|---|
| DP Compliance | DP 1.4 |
|---|
| Video Bandwidth | HDMI: Up to 48Gbps FRL and 18Gbps TMDS | USB-C: Up to 32Gbps |
|---|
| Video Resolution | HDMI: Up to 8K@60Hz 4:2:0 12-bit, 4K@120Hz 4:4:4 12-bit | USB-C: Up to 8K@30Hz 4:2:2 10-bit, 4K@120Hz 4:2:2 10-bit |
|---|
| Color Depth | 8-bit, 10-bit, 12-bit |
|---|
| Color Space | RGB 4:4:4, YCbCr 4:4:4, YCbCr 4:2:2, YCbCr 4:2:0 |
|---|
| HDMI Audio Formats | LPCM, Dolby Digital/Plus/EX, Dolby TrueHD, Dolby Atmos, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DTS:X |
|---|
| HDR Formats | HDR, HDR10, HDR10+, Dolby Vision, HLG |
|---|
| HDMI 2.1 Features | VRR, ALLM, QMS, QFT, SBTM, CEC |
|---|
| ESD Protection | IEC 61000-4-2: ±8kV (Air-gap discharge) & ±4kV (Contact discharge) |
|---|
| Input | 3 × HDMI Type A [19-pin female] | 1 × USB Type C [24-pin female] |
|---|
| Output | 1 × HDMI Type A [19-pin female] |
|---|
| Control | 1 × SERVICE [USB Type C, update port] | 1 × IR Receive Window | 1 × Front Panel Button | 3-Pin EDID DIP Switch |
|---|
| Housing | Metal |
|---|
| Color | Black |
|---|
| Dimensions | 145mm (W) × 68mm (D) × 18mm (H) |
|---|
| Weight | 258g |
|---|
| Power Supply | Input: AC 100~240V 50/60Hz, Output: DC 5V/1A (CE/FCC/UL certified) |
|---|
| Power Consumption | 2.25W (Max) |
|---|
| Operating Temperature | 0°C ~ 40°C / 32°F ~ 104°F |
|---|
| Storage Temperature | -20°C ~ 60°C / -4°F ~ 140°F |
|---|
| Relative Humidity | 20~90% RH (non-condensing) |
|---|
| 8K | 2m / 6.6ft (Ultra HDMI 2.1) |
|---|
| 4K60 | 8m / 26ft |
|---|
| 4K24 | 12m / 39ft |
|---|
| 1080P | 15m / 49ft |
|---|
Questions
- What video resolutions does the SW-4X1HDUSBC support?
- HDMI inputs support up to 8K@60Hz 4:2:0 12-bit and 4K@120Hz 4:4:4 12-bit. The USB-C input supports up to 8K@30Hz 4:2:2 10-bit and 4K@120Hz 4:2:2 10-bit.
- What is the maximum video bandwidth?
- HDMI inputs support up to 48Gbps FRL and 18Gbps TMDS. The USB-C input supports up to 32Gbps with DP 1.4 compliance.
- Does the USB-C input support DP Alt Mode?
- Yes. The USB-C input is DP 1.4 compliant and supports video bandwidth up to 32Gbps via DisplayPort Alternate Mode.
- What EDID modes are available?
- Eight EDID presets via 3-pin DIP switch: copy sink EDID (default), 4K@60Hz 4:4:4 2ch PCM, FRL 12G 8K HDR with 2ch/5.1ch/7.1ch audio options, and FRL 10G 8K HDR with 2ch/5.1ch/7.1ch audio options.
- What power supply is required?
- The included 5V/1A DC power supply (AC 100-240V input). The unit consumes 2.25W maximum.
- What are the dimensions and mounting options?
- 145mm (W) x 68mm (D) x 18mm (H), weighing 258g. The ultrathin metal housing can sit on a desk, mount behind a display with Velcro, or tuck under a conference table. It is not rack-mountable.
- No video output — what should I check?
- Verify the power LED is on (red). Check that the correct input is selected (green LED on IN 1-4). Use Ultra High Speed HDMI cables for 8K (2m max). Try changing the EDID DIP switch to match your display resolution.
- USB-C source not detected?
- Ensure the USB-C cable supports DP Alt Mode. Not all USB-C cables carry video — use a cable rated for DisplayPort or Thunderbolt. Check that the source device has DP Alt Mode enabled.
- Why choose this over a standard 4x1 HDMI switch with a USB-C adapter?
- The native USB-C input eliminates adapter dependency — no signal degradation, no lost dongles, no extra failure points. It supports up to 32Gbps DP 1.4 video natively without conversion overhead.
- What certifications does it have?
- CE, FCC, and UL certified. The universal power supply (AC 100-240V 50/60Hz) supports worldwide deployment.
